CISCO Catalyst 9130AX Series Access Point, Internal Antennas; Wi-Fi 6; 4x4:4 MIMO, B Domain (C9130AXI-B)
CISCO Catalyst 9130AX Series Access Point, Internal Antennas; Wi-Fi 6; 4x4:4 MIMO, B Domain (C9130AXI-B) — photo 2
CISCO Catalyst 9130AX Series Access Point, Internal Antennas; Wi-Fi 6; 4x4:4 MIMO, B Domain (C9130AXI-B) — photo 3

Cisco SKU C9130AXI-B

CISCO Catalyst 9130AX Series Access Point, Internal Antennas; Wi-Fi 6; 4x4:4 MIMO, B Domain (C9130AXI-B)

Wi-Fi 6 certified, supporting 802.11ax on both 2.4-GHz and 5-GHz bands, Up to four Wi-Fi radios: 5GHz flexible radio (single 8×8 or dual 4×4), 2.4GHz (4×4) and Cisco RF ASIC, OFDMA and MU-MIMO

$185.00

Ask an engineer about this model

Add several items, then request a quote at checkout.

  • Free US shipping on orders over $300
  • Manufacturer warranty
  • 30-day returns on unopened items

The Cisco Catalyst C9130AXI-B Access Point is part of the next generation of enterprise access points, offering resilience, security, and intelligence. Equipped with internal antennas, this model supports Wi-Fi 6 and features 4×4:4 MU-MIMO, making it an ideal choice for high-performance wireless connectivity in the B Domain.

Product NameCisco Catalyst 9130AXI-B
Product TypeAccess Point
Wi-Fi Standards802.11ax (Wi-Fi 6), 802.11ac, 802.11n, 802.11a/g
Bands Supported2.4 GHz and 5 GHz
AntennasInternal, 4×4 MIMO on 2.4 GHz and 8×8 MIMO on 5 GHz
Ethernet Ports1x Multigigabit Ethernet (up to 5 Gbps), 1x RJ-45 console
USB Port1x USB 2.0
Operating Temperature0°C to 50°C
Weight1.36 kg
CertificationsCE, FCC, RoHS compliant
Environmental SafetyUses low-halogen components and energy-efficient design
Memory2048 MB DRAM, 1024 MB flash
Data RateUp to 10 Gbps (5 GHz)
MountingWall or ceiling mountable
Power Supply802.3at PoE+, 802.3bt Cisco UPOE
Management FeaturesSupports Cisco DNA, controller-based or standalone operation
Security FeaturesWPA3, AES encryption, secure boot
Dimensions22.6 cm x 22.6 cm x 4.8 cm
LED IndicatorsStatus LEDs for operation and connectivity
  • Wi-Fi 6 certified, supporting 802.11ax on both 2.4-GHz and 5-GHz bands, Up to four Wi-Fi radios: 5GHz flexible radio (single 8×8 or dual 4×4), 2.4GHz (4×4) and Cisco RF ASIC, OFDMA and MU-MIMO.

Cisco Catalyst C9130AXI-B Access Point

The Cisco Catalyst C9130AXI-B Access Point is part of the next generation of enterprise access points, offering resilience, security, and intelligence. Equipped with internal antennas, this model supports Wi-Fi 6 and features 4×4:4 MU-MIMO, making it an ideal choice for high-performance wireless connectivity in the B Domain.

Quick Specs

  • Wi-Fi 6 certified, supporting 802.11ax on both 2.4-GHz and 5-GHz bands.
  • Up to four Wi-Fi radios: 5GHz flexible radio (single 8×8 or dual 4×4), 2.4GHz (4×4) and Cisco RF ASIC.
  • OFDMA and MU-MIMO
  • Multigigabit support
  • Internal antennas
  • IoT ready (BLE, other 802.15.4 protocols like Zigbee, supported in future software releases).
  • Supports Cisco 3500, 5520, 8540, and 9800 series Wireless Controllers.
  • PHY data rates up to 10 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz).
  • 802.11 Dynamic Frequency Selection (DFS) and Cyclic Shift Diversity (CSD) support.
  • WPA3 support
