Cisco ISR4331-SEC/K9 Router
100Mbps-300Mbps system throughput 2 WAN/LAN ports 2 SFP ports multi-Core CPU 1 service module slots Security Voice WAAS Intelligent WAN OnePK AVC
| PoE ports | 530 |
|---|
$3,679.00
Ask an engineer about this modelAdd several items, then request a quote at checkout.
- Free US shipping on orders over $300
- Manufacturer warranty
- 30-day returns on unopened items
Where it fits
The Cisco 4000 Family Integrated Services Router (ISR) enhances WAN communications in enterprise branches and is tailored for application-aware networking in sites with limited IT resources. It consolidates critical IT functions—network, compute, and storage resources—and runs multiple services like encryption and traffic management without affecting data throughput. ISR4331-SEC/K9 operates with default 4GB Flash Memory and 4GB DRAM, which can increase 4 four times.
| Product Family | ISR 4000 Series |
|---|---|
| Product Type | Routers |
| Total onboard WAN or LAN 10/100/1000 ports | 3 |
| RJ-45-based ports | 2 |
| SFP-based ports | 2 |
| Enhanced service- module slots | 1 |
| Aggregate Throughput (Default) | 100 Mbps to 300 Mbp |
| AC input voltage | 100 to 240 VAC autoranging |
| Power-supply options | Internal: AC,DC and PoE |
| Maximum power with AC power supply (watts) | 250 |
| Maximum power with PoE power supply (platform only) (watts) | 530 |
| Unit dimensions in. (W x D x H) | 1.75 x 17.25 x 17.25 |
| Rack-mount 19in | Included |
| Wall-mount | Yes |
| Default memory DDR3 ECC DRAM (data plane) | NA |
| Maximum memory DDR3 ECC DRAM (data plane) | NA |
| Default memory DDR3 ECC DRAM (control/services plane) | NA |
|---|---|
| Maximum memory DDR3 ECC DRAM (control/services plane) | NA |
| Default flash memory | 4 GB |
| Maximum Flash Memory | 16 GB |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Operating humidity | 5% to 85% |
| Safety | UL 60950-1 |
| EMC | 47 CFR, Part 15 |
| Accessories | There is no additional accessories |
| Bundles | Features |
| Application Experience with Voice (AXV) | AX + Voice |
| Voice with Security (VSEC) | Voice + Security |
| Application Experience (AX) | IP Base + Security + advanced networking protocols: L2TPv3, BFD, MPLS, VRF, VXLAN10 (Bandwidth <100Mbps) |
| Voice (V) | IP Base + Unified Communications: CME, SRST, CUBE |
| Security (SEC) | IP Base + Advanced Security: Zone Based Firewall, IPSec VPN, EZVPN, DMVPN, |
The Cisco 4000 Family Integrated Services Router (ISR) enhances WAN communications in enterprise branches and is tailored for application-aware networking in sites with limited IT resources. It consolidates critical IT functions—network, compute, and storage resources—and runs multiple services like encryption and traffic management without affecting data throughput. ISR4331-SEC/K9 operates with default 4GB Flash Memory and 4GB DRAM, which can increase 4 four times.
Key Features
- IP Base + Advanced Security: Zone Based Firewall, IPSec VPN, EZVPN, DMVPN, FlexVPN.
- 3 NIM slots
- Cisco Software Defined WAN (SDWAN)
The tabs contain the ISR4331-SEC/K9 datasheet with all the specifics you need.
