Cisco ISR4431-SEC/K9 Router
500Mbps-1Gbps system throughput 4 WAN/LAN ports 4 SFP ports multi-Core CPU Dual-power Security Voice WAAS Intelligent WAN OnePK AVC
| PoE ports | 500 with PoE redundant |
|---|---|
| Storage | 2 GB |
$9,759.00
Ask an engineer about this modelAdd several items, then request a quote at checkout.
- Free US shipping on orders over $300
- Manufacturer warranty
- 30-day returns on unopened items
Where it fits
The modular Cisco 4000 Series Integrated Services Routers (ISRs) delivers LAN and WAN connectivity, and offer Network Interface Module (NIM) slots as well as Enhanced service module (SM-X) slots. These slots support a plethora of modules that include LAN, WAN, and Wireless Interfaces, and a range of Compute engines that enable embedded services. With its licenses, the ISR4431-SEC/K9 model comes with Security Bundle that offers IP Base + Advanced Security: Zone Based Firewall, IPSec VPN, EZVPN, DMVPNivering over 4Gbps aggregate throughput capacity.
| Product Family | ISR 4000 Series |
|---|---|
| Product Type | Routers |
| Total onboard WAN or LAN 10/100/1000 ports | 4 |
| RJ-45-based ports | 4 |
| SFP-based ports | 4 |
| Enhanced service- module slots | 0 |
| Aggregate Throughput (Default) | 500 Mbps to 1 Gbps |
| AC input voltage | 100 to 240 VAC autoranging |
| Power-supply options | Internal: AC,DC and PoE |
| Maximum power with AC power supply (watts) | 250 (no PoE) |
| Maximum power with PoE power supply (platform only) (watts) | 500 with PoE redundant |
| Unit dimensions in. (W x D x H) | 1.73 x 17.25 x 19.97 |
| Rack-mount 19in | Included |
| Wall-mount | Yes |
| Default memory DDR3 ECC DRAM (data plane) | 2 GB |
| Maximum memory DDR3 ECC DRAM (data plane) | 2 GB |
| Default memory DDR3 ECC DRAM (control/services plane) | 4 GB |
|---|---|
| Maximum memory DDR3 ECC DRAM (control/services plane) | 16 GB |
| Default flash memory | 8 GB |
| Maximum Flash Memory | 32 GB |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Operating humidity | 5% to 85% |
| Safety | UL 60950-1 |
| EMC | 47 CFR, Part 15 |
| Accessories | There is no additional accessories |
| Bundles | Features |
| Application Experience with Voice (AXV) | AX + Voice |
| Voice with Security (VSEC) | Voice + Security |
| Application Experience (AX) | IP Base + Security + advanced networking protocols: L2TPv3, BFD, MPLS, VRF, VXLAN10 (Bandwidth <100Mbps) |
| Voice (V) | IP Base + Unified Communications: CME, SRST, CUBE |
| Security (SEC) | IP Base + Advanced Security: Zone Based Firewall, IPSec VPN, EZVPN, DMVPN |
Cisco ISR4431-SEC/K9 Router Overview
The modular Cisco 4000 Series Integrated Services Routers (ISRs) delivers LAN and WAN connectivity, and offer Network Interface Module (NIM) slots as well as Enhanced service module (SM-X) slots. These slots support a plethora of modules that include LAN, WAN, and Wireless Interfaces, and a range of Compute engines that enable embedded services. With its licenses, the ISR4431-SEC/K9 model comes with Security Bundle that offers IP Base + Advanced Security: Zone Based Firewall, IPSec VPN, EZVPN, DMVPNivering over 4Gbps aggregate throughput capacity.
Key Features
- Intent-based Cisco DNA
- Over 4Gbps aggregate throughput capacity w/ license
- Cisco® Software Defined WAN (SDWAN)
The tabs contain the ISR4431-SEC/K9 datasheet with all the specifics you need.Key Features.
