Fortinet FS-248E-FPOE Switch
Layer 2/3 FortiGate switch controller compatible PoE+ switch with 48 x GE RJ45 ports, 4 x GE SFP, with automatic Max 740W POE output limit
| Ports | 48x GE RJ45 ports and 4x GE SFP ports |
|---|---|
| PoE ports | 48 (802.3af/802.3at) |
| PoE budget | 740 W |
| Form factor | 1 RU Rack Mount |
| Switching capacity | 104 Gbps |
$2,120.90
Ask an engineer about this modelAdd several items, then request a quote at checkout.
- Free US shipping on orders over $300
- Manufacturer warranty
- 30-day returns on unopened items
Where it fits
The FS-248E-FPOE switch is equipped with PoE+ technology, streamlining network deployment and reducing cable congestion. With 52 ports, it is suitable for high-density business applications. This rack-mountable switch includes integrated monitoring features, such as port mirroring, to facilitate efficient and accurate troubleshooting. It adheres to IEEE standards such as LLPD and LACP, enhancing its versatility.
| Product Family | FortiSwitch |
|---|---|
| Product Type | Switch |
| Total Network Interfaces | 48x GE RJ45 ports and 4x GE SFP ports |
| Dedicated Management 10/100/1000 Ports | 1 |
| RJ-45 Serial Console Port | 1 |
| Form Factor | 1 RU Rack Mount |
| Power over Ethernet (PoE) Ports | 48 (802.3af/802.3at) |
| PoE Power Budget (single/dual PSU) | 740 W |
| Mean Time Between Failures | > 10 years |
| Switching Capacity (Duplex) | 104 Gbps |
| Packets Per Second (Duplex) | 155 Mpps |
| MAC Address Storage | 16 K |
| Network Latency | < 1µs |
| VLANs Supported | 4 K |
| Link Aggregation Group Size | 8 |
| Total Link Aggregation Groups | Up to number of ports |
| Packet Buffers | 1.5 MB |
| DRAM | 512 MB DDR3 |
|---|---|
| FLASH | 128 MB |
| ACL | 512 |
| Spanning Tree Instances | 16 |
| Route Entries (IPv4/IPv6) | 64/32 |
| Multicast Route Entries | – |
| Host Entries | 512 |
| Dimensions in | 1.73 x 16.1 x 17.3 |
| Power Required | 100–240V AC, 50-60 Hz |
| Power Supply | AC built in |
| Redundant Power | Optional FRPS-740 |
| Power Consumption (Average / Maximum) | 842 W / 855.02 W |
| Heat Dissipation | 162.87865 BTU/h |
| Operating Temperature | 32–122°F (0–50°C) |
| Certification | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 |
| FRPS-740 | Redundant AC power supply for up to 2 units: FS-224D-FPOE, FS-224E-POE, FS-248E-POE, FS-248E-FPOE |
The FS-248E-FPOE switch is equipped with PoE+ technology, streamlining network deployment and reducing cable congestion. With 52 ports, it is suitable for high-density business applications. This rack-mountable switch includes integrated monitoring features, such as port mirroring, to facilitate efficient and accurate troubleshooting. It adheres to IEEE standards such as LLPD and LACP, enhancing its versatility.
Quick Specs
- 48x GE RJ45 ports
- 4x GE SFP uplink ports
- Rack-mountable
- 48x PoE Ports
