Name: HPE Aruba Networking JL484A 25G SFP28 LC SR 100m MMF Transceiver
SKU: JL484A-NEW
Price: 999 USD
Availability: InStock

HPE Aruba Networking JL484A 25G SFP28 LC SR 100m MMF Transceiver

The 25G SFP28 LC SR Transceiver (JL484A) is a compact and high-performance optical transceiver designed for short-range, multimode fiber (MMF) connections up to 100 meters.

Categories: Modules & Cards, TransceiversSKU: JL484A-NEW

Price

$999.00

1-Year Manufacturer Warranty

Free Shipping on Orders Over $500

Secure Payment

Description
Additional information

Properties	HPE Aruba 25G SFP28 LC SR 100m MMF Transceiver (JL484A)
Description	The 25G SFP28 LC SR Transceiver (JL484A) is a compact and high-performance optical transceiver designed for short-range, multimode fiber (MMF) connections up to 100 meters.
Product Family	HPE Aruba Transceivers
Product Type	Transceiver Module
Key Features	• Form Factor: Small Form-factor Pluggable (SFP28) • Interface (Connector): LC Duplex • Data Rate: 25 Gigabit Ethernet • Maximum Distance: Up to 100 meters over Multimode Fiber (MMF) • Wavelength: 850nm • Fiber Type: Multi-mode • Compatibility: Compatible with HPE Aruba switches and devices supporting SFP28 interfaces • Hot-swappable: Supports hot-swapping for easy installation and replacement • Optical Monitoring (DOM): Digital Optical Monitoring for real-time monitoring of transceiver parameters • Quality and Reliability: Manufactured by HPE Aruba, ensuring high quality and reliability • Standards Compliance: Compliant with IEEE 802.3by standard for 25GbE

Specifications	25G SFP28 LC SR 100m MMF Transceiver – JL484A
Form Factor	SFP28
Connectors	Dual LC connector
DOM	Yes
Fiber Diameter	50/125
Wavelength (nm)	850
Fiber Type	MMF
Max Distance	70m over OM3(2000) / 100m over OM4(4700)
Fiber-loss budgets: Transmit (dBm) (Min-Max)	-8.4 to +2.4
Fiber-loss budgets: Receive (dBm) (Min-Max)	-10.3 to +2.4
Power consumption	Up to 1W per port
Temperature Range	0 to 70°C (32 to 158°F)

HPE ARUBA 25G SFP28 LC SR 100M MMF TRANSCEIVER (JL484A)

The JL484A HPE Aruba 25G SFP28 LC SR 100M MMF Transceiver is a compact, pluggable transceiver module designed for high-speed networking applications. Designed for use with HPE Aruba switches and routers, this transceiver is capable of transmitting data at 25 Gbps over distances up to 100 meters. Equipped with an LC connector, a standard interface for fiber optic cable, this transceiver ensures compatibility with various types of fiber optic cable. It is designed as a small form-factor pluggable (SFP28) module.
