HPE Aruba Networking JZ337A AP-535

Managed, Indoor Access Point, Dual-Radio 4×4 MIMO, 802.11ax (Wi-Fi 6), up to 3.55Gbps, IoT (Bluetooth 5 & Zigbee), WPA3 Security Product Name HPE Aruba JZ337A AP-535 Access Point Product Description Dual-radio 4×4 802.11ax (Wi-Fi 6) Unified Campus AP designed for high-density deployments, with

Categories: Access Points, NetworkingSKU: JZ337A-NEW

Price

1-Year Manufacturer Warranty

Free Shipping on Orders Over $500

Secure Payment

Description
Additional information

Managed, Indoor Access Point, Dual-Radio 4×4 MIMO, 802.11ax (Wi-Fi 6), up to 3.55Gbps, IoT (Bluetooth 5 & Zigbee), WPA3 Security

Product Name	HPE Aruba JZ337A AP-535 Access Point
Product Description	Dual-radio 4×4 802.11ax (Wi-Fi 6) Unified Campus AP designed for high-density deployments, with integrated IoT radios, WPA3 security, and Intelligent Power Monitoring.
Wi-Fi Standard	802.11ax (Wi-Fi 6)
Maximum Data Rate	Up to 3.55 Gbps
Radio Configuration	Dual-radio, 4×4 MIMO on both 2.4 GHz and 5 GHz bands
Client Capacity	Supports up to 1,024 associated client devices per radio
OFDMA Support	Yes, uplink and downlink
MU-MIMO Support	Yes, bi-directional
IoT Connectivity	Bluetooth 5 and Zigbee radios integrated
Security Features	WPA, WPA2, WPA3, Enhanced Open (OWE), Enterprise CNSA option
Power Monitoring	Intelligent Power Monitoring (IPM) for optimal performance under PoE constraints

Antenna Type	Four integrated dual-band downtilt omnidirectional antennas for 4×4 MIMO; peak antenna gain: 3.5 dBi (2.4 GHz), 5.4 dBi (5 GHz)
Ethernet Ports	(2) HPE Smart Rate RJ-45 ports, auto-negotiating up to 5Gbps
Power Options	IEEE 802.3bt (Class 5) or dual 802.3at PoE; optional direct DC power
Mounting Options	Ceiling or wall mountable
Operating Temperature	0°C to 50°C (32°F to 122°F)
Dimensions	`80 mm x 270 mm x 270 mm (3.1 x 10.6 x 10.6 in)` (AP-535 spec)
Weight	1.0 kg (2.2 lbs)
Management Options	Aruba Central (cloud-managed) or Aruba AirWave (on-premises)
Certifications	UL2043 plenum rated; Wi-Fi Alliance: a/b/g/n/ac, Wi-Fi 6 (ax), WPA/WPA2/WPA3, Enhanced Open (OWE), WMM, Agile Multiband, Wi-Fi Location; Bluetooth SIG

HPE Aruba AP-535 (JZ337A) Dual-Radio Wi-Fi 6 Access Point

The Aruba 530 Series AP-535 delivers enterprise-grade Wi-Fi 6 performance for high-density deployments such as campuses, schools, retail, and hospitality. With dual-radio 4×4 MIMO and peak data rates up to 3.55 Gbps, it ensures seamless connectivity for mobile and IoT devices.

Equipped with Bluetooth 5 and Zigbee radios, the AP-535 extends IoT location and monitoring services, while WPA3, Enhanced Open, and WPA2 Enterprise safeguard wireless traffic. Aruba’s Intelligent Power Monitoring (IPM) dynamically adapts features under PoE constraints, ensuring optimal performance.

Key Features

Dual-radio 802.11ax (Wi-Fi 6) with 4×4 MIMO on both 2.4 GHz & 5 GHz
Aggregate throughput: up to 3.55 Gbps
Integrated Bluetooth 5 & Zigbee for IoT connectivity
Security: WPA/WPA2/WPA3, Enhanced Open (OWE), Enterprise CNSA
Flexible power: IEEE 802.3bt (Class 5), dual 802.3at, or DC power
HPE Smart Rate 5GbE ports for high-capacity backhaul
Cloud or on-premises management with Aruba Central or AirWave

Technical Specs

Antennas: 4x dual-band omni; gain 3.5 dBi (2.4 GHz), 5.4 dBi (5 GHz)
Ports: 2x RJ-45 HPE Smart Rate (up to 5 Gbps)
Power consumption: 25W–30W PoE, 29W DC
Dimensions: 80 x 270 x 270 mm; Weight: 1.0 kg
Certifications: UL2043, Wi-Fi 6 certified, Bluetooth SIG

Weight	5.0 lbs
Ports	(2) HPE Smart Rate RJ-45 ports, auto-negotiating up to 5Gbps
Speed	Up to 3.55 Gbps
Power	Intelligent Power Monitoring (IPM) for optimal performance under PoE constraints
Connectivity	Bluetooth 5 and Zigbee radios integrated
Wireless Standard	802.11ax (Wi-Fi 6)
Capacity	Supports up to 1,024 associated client devices per radio
Brand	HPE Aruba
