Juniper EX2300-C-12T-VC Switch with Virtual Chassis License
Switch L3 managed 12 x 10/100/1000 + 2 x Gigabit SFP / 10 Gigabit SFP+ rack-mountable with Virtual Chassis License
$772.80
Ask an engineer about this modelAdd several items, then request a quote at checkout.
- Free US shipping on orders over $300
- Manufacturer warranty
- 30-day returns on unopened items
Where it fits
The Juniper Networks EX2300-C-12T-VC Ethernet Switch provides a cost-effective, introductory-level solution in a small, fanless design for access layer deployments in branch, retail, and workgroup settings. The EX2300-C is compatible with Juniper’s distinctive Virtual Chassis technology, allowing for the management of up to four interconnected EX2300-C switches as a unified logical device. This feature provides a scalable, incremental solution for expanding network environments. The EX2300-C-12T-VC model is equipped with 12 ports of 10/100/1000BASE-T, along with 2 x 1/10GbE SFP/SFP+ and includes a Virtual Chassis License (optics are sold separately).
| Product Family | EX2300-C Series |
|---|---|
| Product Type | Ethernet Switch |
| GbE Port Density | 14 (12 access ports + 2 uplink ports) |
| Dimensions (HxWxD) Inches | 10.98 x 1.72 x 9.4 in (27.9 x 4.4 x 23.9 cm) |
| Weight | 5.45 lb (2.48 kg) |
| Cooling | Fanless Operation |
| Backplane | 40 Gbps Virtual Chassis interconnect to link up to four switches as a single logical device |
| Product Options | Access Port Configuration |
| Access Port Configuration | 12-port 10/100/1000BASE-T |
| Uplink Ports | Two SFP/SFP+ ports |
| PoE+ Capable Ports | 0 |
| Height | 1 RU |
| PoE+ Budget | N/A |
| Power Supply Rating | 40 W AC |
| Max. System Power Consumption (Input Power without PoE) | Total PoE Power Budget |
| 20 W AC | 0 |
| Acoustic Noise in DB | 0 DB (Fanless) |
| DRAM | 2 GB with ECC |
| Flash Memory | 2 GB |
| CPU | 1.25GHz ARM CPU |
| Packet-Switching Capacities | 32 Gbps (unidirectional)/64 Gbps (bidirectional) |
| Management and Analytics Platforms | Juniper Mist Wired Assurance for Campus Junos Space® Network Director for Campus Junos Space® Management |
| Operating temperature | 32° to 104° F (0° to 40° C) |
| Storage temperature | 40° to 158° F (-40° to 70° C) |
| Operating altitude | up to 5.000 ft (1524 m) |
| Non-operating altitude | up to 16,000 ft (4877 m) |
| Relative humidity operating | 10% to 85% (noncondensing) |
| Relative humidity non-operating | 0% to 95% (noncondensing) |
| Electromagnetic Compatibility Certifications | FCC 47CFR Part 15 Class A EN 55022 Class A ICES-003 Class A VCCI Class A AS/NZS CISPR 22 Class A CISPR 22 Class A EN 55024 EN 300386 CE |
| Telecom Quality Management | TL9000 |
| Telco | CLEI code |
| EX-CBL-CON-USB | Console cable with USB Type A and mini-B connectors |
| EX2300-C-CBL-GRD | Cable guard |
| EX2300-C-MGNT-MNT | Magnet mount |
| EX2300-C-RMK | Rack-mount kit |
|---|---|
| S-EX-A-C1-3 | Software, EX Series Advanced license, Class 1 (12 ports), includes Wired Assurance subscription for EX Series 12-port switches, 3 year |
| S-EX-A-C1-5 | Software, EX Series Advanced license, Class 1 (12 ports), includes Wired Assurance subscription for EX Series 12-port switches, 5 year |
| S-EX-A-C1-3-COR | Software, EX Series Advanced license, Class 1 (12 ports), includes Wired Assurance subscription for EX Series 12-port switches with SVC CORE support, 3 year |
| S-EX-A-C1-5-COR | Software, EX Series Advanced license, Class 1 (12 ports), includes Wired Assurance subscription for EX Series 12-port switches with SVC CORE support, 5 year |
| S-EX-A-C2-P | Software, EX Series Advanced license, Class 2 Perpetual license for 12-port switches |
| EX-12-EFL | Enhanced Feature License for EX2300 12 port switches |
| EX-SFP-10GE-USR | SFP+ 10-Gigabit Ethernet Ultra Short Reach Optics, 850 nm for 10m on OM1, 20m on OM2, 100m on OM3 multimode fiber |
| EX-SFP-10GE-DAC-1M | SFP+ 10-Gigabit Ethernet Direct Attach Copper (twinax copper cable), 1m |
| EX-SFP-10GE-SR | SFP+ 10GBASE-LR; LC connector; 1310 nm; 10km reach on single-mode fiber |
| EX-SFP-10GE-LR | SFP+ 10GBASE-LR; LC connector; 1310 nm; 10km reach on single-mode fiber |
| EX-SFP-10GE-DAC-3M | SFP+ 10-Gigabit Ethernet Direct Attach Copper (twinax copper cable), 3m |
| EX-SFP-10GE-DAC-5M | SFP+ 10-Gigabit Ethernet Direct Attach Copper (twinax copper cable), 5m |
| EX-SFP-1GE-SX | SFP 1000BASE-SX; LC connector; 850 nm; 550m reach on multimode fiber |
| EX-SFP-1GE-SX-ET | Extended Temperature SFP 1000BASE-SX; LC connector; 850 nm; 550m reach on multimode fiber |
| EX-SFP-1GE-LX | SFP 1000BASE-LX; LC connector; 1310 nm; 10 km reach on single-mode fiber |
| EX-SFP-1GE-LH | SFP 1000BASE-LH Gigabit Ethernet Optics, 1550 nm for 70 km transmission on single-mode fiber |
| EX-SFP-1GE-T | SFP 10/100/1000BASE-T Copper Transceiver Module for up to 100m transmission on Category |
| EX-SFP-1GE-LX40K | SFP 1000BASE-LX Gigabit Ethernet Optics, 1310 nm for 40 km transmission on single-mode fiber |
| EX-SFP-GE10KT13R14 | SFP 1000BASE-BX Gigabit Ethernet Optics, Tx 1310 nm/Rx 1490 nm for 10 km transmission on single strand of single-mode fiber |
| EX-SFP-GE10KT14R13 | SFP 1000BASE-BX Gigabit Ethernet Optics, Tx 1490 nm/Rx 1310 nm for 10 km transmission on single strand of single-mode fiber |
| EX-SFP-GE10KT13R15 | SFP 1000BASE-BX Gigabit Ethernet Optics, Tx 1310 nm/Rx 1550 nm for 10 km transmission on single strand of single-mode fiber |
| EX-SFP-GE10KT15R13 | SFP 1000BASE-BX Gigabit Ethernet Optics, Tx 1550 nm/Rx 1310 nm for 10 km transmission on single strand of single-mode fiber |
| EX-SFP-GE40KT13R15 | SFP 1000BASE-BX Gigabit Ethernet Optics, Tx 1310 nm/Rx 1550 nm for 40 km transmission on single strand of single-mode fiber |
| EX-SFP-GE40KT15R13 | SFP 1000BASE-BX Gigabit Ethernet Optics, Tx 1550 nm/Rx 1310 nm for 40 km transmission on single strand of single-mode fiber |
| EX-SFP-GE80KCW1470 | SFP Gigabit Ethernet CWDM, LC connector; 1470 nm, 80 km reach on single-mode fiber |
| EX-SFP-GE80KCW1490 | SFP Gigabit Ethernet CWDM, LC connector; 1490 nm, 80 km reach on single-mode fiber |
| EX-SFP-GE80KCW1510 | SFP Gigabit Ethernet CWDM, LC connector; 1510 nm, 80 km reach on single-mode fiber |
| EX-SFP-GE80KCW1530 | SFP Gigabit Ethernet CWDM, LC connector; 1530 nm, 80 km reach on single-mode fiber |
| EX-SFP-GE80KCW1550 | SFP Gigabit Ethernet CWDM, LC connector; 1550 nm, 80 km reach on single-mode fiber |
| EX-SFP-GE80KCW1570 | SFP Gigabit Ethernet CWDM, LC connector; 1570 nm, 80 km reach on single-mode fiber |
| EX-SFP-GE80KCW1590 | SFP Gigabit Ethernet CWDM, LC connector; 1590 nm, 80 km reach on single-mode fiber |
| EX-SFP-GE80KCW1610 | SFP Gigabit Ethernet CWDM, LC connector; 1610 nm, 80 km reach on single-mode fiber |
The Juniper Networks EX2300-C-12T-VC Ethernet Switch provides a cost-effective, introductory-level solution in a small, fanless design for access layer deployments in branch, retail, and workgroup settings. The EX2300-C is compatible with Juniper’s distinctive Virtual Chassis technology, allowing for the management of up to four interconnected EX2300-C switches as a unified logical device. This feature provides a scalable, incremental solution for expanding network environments. The EX2300-C-12T-VC model is equipped with 12 ports of 10/100/1000BASE-T, along with 2 x 1/10GbE SFP/SFP+ and includes a Virtual Chassis License (optics are sold separately).
Quick Specs
- 12x 10/100/1000BASE-T
- 2x 1/10GbE SFP/SFP+ ports uplink (optics sold separately)
- 2 GB with ECC RAM
- Virtual Chassis License
