Mellanox MCX653106A-HDAL Network Adapter Card

Mellanox SKU MCX653106A-HDAL

Mellanox MCX653106A-HDAL Network Adapter Card

400 Gigabit Ethernet Four QSFP56 ports PCIe 4.0 x16 interface Crypto support Thumbscrew (Pull Tab) Bracket

Ports	PCIe Gen 3.0 / 4.0 x16

$785.00

Ask an engineer about this model

Add several items, then request a quote at checkout.

Free US shipping on orders over $300
Manufacturer warranty
30-day returns on unopened items

The Mellanox MCX653106A-HDAL is a member of the ConnectX-6 Ethernet Adapter Cards family. This product offers the highest performance, PCIe Gen 3.0 and Gen 4.0 support, and Mellanox Host Daisy-chaining technology for economical rack design for compute and storage infrastructures. This card is an excellent choice for servers that need high-performance networking, scalability, reliability, and security. It is ideal for use in data centers, high-performance computing, cloud computing, telecom, and enterprise networks.

Product Name	Mellanox MCX653106A-HDAL
Product Family	ConnectX-6 Ethernet Adapter Cards
Product Type	Network Adapter Card
Interface	PCIe Gen 3.0/4.0 x16
Ports	Dual QSFP56
Data Rate	Supports 1/10/25/40/50/100/200 Gb/s Ethernet
Latency	Sub-600ns
Message Rate	Up to 215 million messages per second
Form Factor	Standard full-height card with cold plate for liquid cooling
Dimensions (H x W)	6.6 in. x 2.71 in. (167.65mm x 68.90mm)

Power Consumption	Typical: 18.5W with passive cables
Operating Temperature	0°C to 55°C
Storage Temperature	40°C to 70°C
Operating Humidity	10% to 85% relative humidity
Storage Humidity	10% to 90% relative humidity
Altitude (Operational)	Up to 3050m
Compliance	RoHS Compliant
Safety Certifications	CB, cTUVus, CE
EMC Certifications	CE, FCC, VCCI, ICES, RCM, KC
Regulatory Compliance	Safety: CB, cTUVus, CE; EMC: CE, FCC, VCCI, ICES, RCM, KC; RoHS: Compliant
