HPE Aruba Networking JL072A 3810M 48G Switch
Managed Layer 3, Rack-mountable, 48 x 1G ports, 1 open module slot for SFP+/40GbE uplinks, No PoE
| Switching capacity | 320 Gbps |
|---|
$3,975.00
Ask an engineer about this modelAdd several items, then request a quote at checkout.
- Free US shipping on orders over $300
- Manufacturer warranty
- 30-day returns on unopened items
Where it fits
The HPE Aruba 3810M 48G Switch (JL072A) is a high-performance Layer 3 switch designed for enterprises and SMBs looking for flexibility and scalability. With 48 Gigabit Ethernet ports, it provides seamless connectivity for devices across the network. It also features an open module slot that supports up to 4 SFP+ ports or 2 40GbE ports, making it adaptable for future network expansions.
| Product Name | JL072A |
|---|---|
| Transceiver Type | SFP+ (Small Form-Factor Pluggable Plus) |
| Data Rate | 10 Gbps |
| Connector Type | RJ-45 |
| Maximum Distance | 30 meters over Cat6a/Cat7 cables |
| Cable Type | Cat6a or Cat7 copper |
| Digital Diagnostic Monitoring | No |
| Hot-Swappable | Yes |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | 40°C to 85°C (-40°F to 185°F) |
| Power Consumption | 2.5W (maximum) |
| Dimensions | 4.39 x 44.25 x 43.13 cm (1U) |
| Weight | 5.99 kg |
| Compatibility | Compatible with HPE Aruba and other networking equipment supporting 10GBASE-T |
| Usage | Data centers, enterprise networks, and server-to-switch connectivity |
| Durability | Rugged design for reliable high-speed data transmission over copper |
| Form Factor | SFP+ MSA compliant |
| Supported Standards | IEEE 802.3an (10GBASE-T) |
| Certifications | CE, FCC, RoHS compliant |
| Environmental Safety | Compliant with environmental standards, mercury-free |
| EMC Compliance | Meets international EMC standards for network equipment |
|---|---|
| Transmission Media | Cat6a or Cat7 copper cables |
| Signal Integrity | Supports stable data transmission up to 30 meters |
| Hot-Swappable | Yes, can be replaced without powering down the system |
| MTBF | 1,500,000 hours |
| Latency | Approximately 2.6 microseconds over 30 meters |
| Power Supply | 3.3V DC |
| Monitoring | Not supported |
| Installation | Plug-and-play installation for quick deployment |
| Deployment | Ideal for short-reach, high-speed networking within data centers and server rooms |
| Firmware Compatibility | Firmware updates supported for enhanced performance |
| Category | Specifications |
| Product Code | JL072A |
| Type | Aruba 3810M 48G 1-slot Switch |
| Power Supplies | Supports up to 2 power supply slots, 1 minimum required (ordered separately) |
| Fan Tray | Includes 1 x JL088A Fan Tray |
| Physical Dimensions | Dimensions (H x W x D): 4.39 x 44.25 x 43.13 cm (1U height) Weight: 5.99 kg |
| Environment | Operating temperature: 0°C to 45°C (32°F to 113°F) Operating humidity: 15% to 95% non-condensing Altitude: Up to 10,000 ft (3 km) |
| Safety | EN 60950/IEC 60950 UL 60950-1 CSA 22.2 60950-1 EN62479:2010 IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013 |
| Emissions | FCC Class A VCCI Class A EN 55022/CISPR 22 Class A EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013 |
- Managed Layer 3, Rack-mountable, 48 x 1G ports, 1 open module slot for SFP+/40GbE uplinks, No PoE.
HPE Aruba 3810M 48G Switch (JL072A)
The HPE Aruba 3810M 48G Switch (JL072A) is a high-performance Layer 3 switch designed for enterprises and SMBs looking for flexibility and scalability. With 48 Gigabit Ethernet ports, it provides seamless connectivity for devices across the network. It also features an open module slot that supports up to 4 SFP+ ports or 2 40GbE ports, making it adaptable for future network expansions.
Key Features
- 48 x 1GbE Ports: Provides fast and reliable connections for a variety of devices.
- Modular Uplinks: Supports optional uplink modules, including 1G, 10G, and 40G for future network growth.
- Advanced Layer 3 Features: Includes OSPF, dynamic routing, and policy-based routing for better network management.
- Stacking Capability: Supports backplane stacking for increased resiliency and scalability in high-demand environments.
- Easy Management: Managed through Aruba Central, AirWave, and CLI for simplified control and monitoring.
Technical Overview
- Recommended for: Enterprise networks, branch offices, and growing SMBs.
- Ports: 48 x 1GbE ports, 1 open module slot for SFP+ or 40GbE uplinks.
- Switching Capacity: 320 Gbps
- Forwarding Rate: 190.5 Mpps
- Layer 3 Features: Supports OSPF, BGP, IPv6, QoS, and policy-based routing.
- Management: Managed through Aruba Central, AirWave, CLI, and web-based GUI.
- Energy Efficiency: Compliant with IEEE 802.3az standards for energy-efficient operation.
Specifications
