Mellanox MCX621102AN-ADAT Network Adapter
ConnectX-6 Dx EN adapter card, 25GbE, Dual-port SFP28, PCIe 4.0 x8, No Crypto, Tall Bracket Product Name NVIDIA ConnectX-6 Dx EN Adapter Card (MCX556A-EDAT) Product Description The NVIDIA ConnectX-6 Dx EN Adapter Card (MCX556A-EDAT) is a high-performance network adapter designed for data centers
Price
1-Year Manufacturer Warranty
Free Shipping on Orders Over $500
Secure Payment
- ConnectX-6 Dx EN adapter card, 25GbE, Dual-port SFP28, PCIe 4.0 x8, No Crypto, Tall Bracket
| Product Name | NVIDIA ConnectX-6 Dx EN Adapter Card (MCX556A-EDAT) |
| Product Description | The NVIDIA ConnectX-6 Dx EN Adapter Card (MCX556A-EDAT) is a high-performance network adapter designed for data centers and high-performance computing environments. It features dual 25GbE SFP28 ports, supports PCIe 4.0 x8 interface, and offers low latency and high message rate capabilities. |
| Product Family | NVIDIA ConnectX-6 Dx Series |
| Product Type | Network Adapter Card |
| Connector | Dual SFP28 Ethernet (copper and optical) |
| Form Factor | Full-Height, Half-Length (FHHL) |
| Data Rate | Ethernet: 1/10/25 Gb/s |
| PCI Express Gen 3.0/4.0 | SERDES @ 16.0 GT/s, 8 lanes (2.0 and 1.1 compatible) |
| Voltage | 3.3V Auxiliary |
| Maximum Current | 100 mA |
| Typical Power (PCIe Gen 4.0) | 11.29 W |
| Size | 4.89 in x 2.71 in (124.22 mm x 68.90 mm) |
| Weight | Not specified |
| Message Rate | 215 Mpps |
| Sub 0.8 µs latency | Yes |
| Supported Architectures | x86, Power, Arm |
| Maximum Power (PCIe Gen 4.0) | 15.96 W |
| Airflow Requirements | – Passive Cable: 200 LFM<br>- Active 0.8W Cable: 400 LFM<br>- Active 1.5W Cable: 450 LFM |
| Maximum Power Available Through SFP28 Port | 1.5 W per port |
| Operating Temperature | – Operational: 0°C to 55°C<br>- Non-operational: -40°C to 70°C |
| Humidity | – Operational: 10% to 85% relative humidity<br>- Non-operational: 10% to 90% relative humidity |
| Altitude (Operational) | 3050 m |
| Regulatory Compliance | Safety: CB / cTUVus / CE<br>EMC: CE / FCC / VCCI / ICES / RCM<br>RoHS: RoHS compliant |
Mellanox MCX621102AN-ADAT Network Adapter
The Mellanox MCX621102AN-ADAT is a member of the Connext-6 Ethernet Adapter Cards family. This adapter card has dual port capabilities and 25Gb Ethernet support and is designed explicitly for PCIe 4.0 x8 slots. It provides a combination of high speed, flexibility, and effectiveness. It is tailored to address the requirements of data centers, cloud environments, and high-performance computing, this adapter card serves as a robust solution for facilitating smooth and rapid communication.
Quick Specs:
- 8x PCIe 4.0
- Message rate: 215 Mpps
- Supports x86, Power and Arm architectures
- Sub 0.8 usec latency
Please see the related tabs for the MCX621102AN-ADAT datasheet and compatible accessories.
| Weight | 5.0 lbs |
|---|---|
| Speed | |
| Form Factor | |
| Power | |
| Brand |
