HPE Aruba Networking JL357A 2540 48G PoE+ 4SFP+ Switch
$3,021.34
HPE Aruba Networking JL727B CX 6200F 48G Class‑4 PoE 4SFP+ 370W Switch
Managed, Rack-mountable, 48 x 1G ports, Fixed Uplinks (4 x SFP+), PoE+ (370W), Layer 3
| Switching capacity | 176 Gbps |
|---|
$3,295.00
Ask an engineer about this modelAdd several items, then request a quote at checkout.
- Free US shipping on orders over $300
- Manufacturer warranty
- 30-day returns on unopened items
Where it fits
The HPE Aruba Networking CX 6200F 48G Class-4 PoE 4SFP+ 370W Switch (JL727B) offers robust, high-performance networking for growing businesses and enterprise environments. With 48 Gigabit Ethernet PoE+ ports and 4 SFP+ uplinks, this switch provides reliable connectivity and power delivery to PoE-enabled devices such as access points, IP phones, and cameras. The 370W PoE power budget ensures sufficient power for connected devices, while its advanced Layer 2 and Layer 3 features enable efficient network segmentation and management.
| Product Family | HPE Aruba Networking CX 6200 Switch Series |
|---|---|
| Product Type | Switch |
| Power supplies | Fixed power supply Up to 370W of Class 4 PoE Power |
| Fans | Fixed fans |
| Dimensions | 4.39 x 44.2 cm x 32.7 cm (1.73 x 17.4 x 12.9 in) |
| Configuration weight | 4.87 kg (10.74 lbs) |
| CPU | Quad Core ARM Cortex™ A72 @ 1.8 GHz |
| Memory and flash | 8 GB DDR4 16 GB eMMC |
| Packet buffer | 8 MB (6 MB + 2 MB) |
| Model switching capacity | 176 Gbps |
| Model throughput capacity | Up to 130.9Mpps |
| Average latency (LIFO-64- bytes packets) | 1 Gbps: 2.28 μSec 10 Gbps: 1.46 μSec |
| Stack size | 8 members (with other 24/48p 6200F and 6200M switches only) |
| Max. stacking distance | Up to 10 kms with long range transceivers |
| Stacking bandwidth | Up to 40Gbps |
| Switched virtual interfaces (dual stack) | 256 |
| IPv4 host table (ARP) | 8,192 |
| IPv6 host table (ND) | 8,192 |
| IPv4 unicast routes | 2,048 |
| IPv6 unicast routes | 1,024 |
| MAC table capacity | 32,768 |
| IGMP groups | 1,024 |
| MLD groups | 1,024 |
| IPv4/IPv6/MAC ACL entries (ingress) | 5,120/1,280/5,120 |
| IPv4/IPv6/MAC ACL entries (egress) | 2,048/512/2,048 |
| Operating temperature | 32°F to 113°F (0°C to 45°C) up to 5,000 ft; derate 1°C for every 1,000 ft from 5,000 ft to 10,000 ft |
| Operating relative humidity | 5% to 95% @ 104°F (40°C) non-condensing |
| Non-operating | (-40°F to 158°F) (-40°C to 70°C) up to 15,000 ft |
|---|---|
| Non-operating storage relative humidity | 5% to 95% @ 149°F (65°C) non-condensing |
| Max operating altitude | 10,000 feet (3.048 km) Max |
| Max non-operating altitude | 15,000 feet (4.6 km) Max |
| Acoustic | Sound Power, LWAd = 5.2 Bel Sound Pressure, LpAm (Bystander) = 36.8 dB |
| Primary airflow | Front and side to back |
| Frequency | 50Hz/60Hz |
| AC voltage | 100V–120/200V–240V, rated |
| Current (for voltages listed above) | 5.2A/2.6A |
| 80plus.org certification | (-) |
| Maximum heat dissipation BTU/hr and kj/hr | 194 BTU/hr 205 kj/hr |
| Power consumption (230VAC) | 76W |
| Lasers | EN 60825-1:2007 IEC 60825-1:2007 Class 1 Class 1 Laser Products/Laser Klasse 1 (Applicable for accessories—Optical Transceivers only) |
| Generic | CISPR 35: 2016 |
| EN | EN 55035:2017 +A11:2020 |
| ESD | IEC 61000-4-2 |
| Radiated | IEC 61000-4-3 |
| EFT/Burst | IEC 61000-4-4 |
| Surge | IEC 61000-4-5 |
| Conducted | IEC 61000-4-6 |
| Power frequency magnetic field | IEC 61000-4-8 |
| Voltage dips and interruptions | IEC 61000-4-11 |
| Harmonics | IEC 61000-3-2, EN 61000-3-2 |
| Flicker | IEC 61000-3-3, EN 61000-3-3 |
| RoHs | EN 63000:2018/IEC 63000:2018 |
| Mounting and enclosure | Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet. Horizontal surface mounting only. 2-post rack kit included |
| Cables | HPE Aruba Networking 10G SFP+ to SFP+ 1m Direct Attach Copper Cable (J9281D) • HPE Aruba Networking 10G SFP+ to SFP+ 3m Direct Attach Copper Cable (J9283D) |
- Managed, Rack-mountable, 48 x 1G ports, Fixed Uplinks (4 x SFP+), PoE+ (370W), Layer 3.
HPE Aruba Networking CX 6200F 48G Class-4 PoE 4SFP+ 370W Switch (JL727B)
The HPE Aruba Networking CX 6200F 48G Class-4 PoE 4SFP+ 370W Switch (JL727B) offers robust, high-performance networking for growing businesses and enterprise environments. With 48 Gigabit Ethernet PoE+ ports and 4 SFP+ uplinks, this switch provides reliable connectivity and power delivery to PoE-enabled devices such as access points, IP phones, and cameras. The 370W PoE power budget ensures sufficient power for connected devices, while its advanced Layer 2 and Layer 3 features enable efficient network segmentation and management.
Key Features
- 48 x 1GbE PoE+ Ports: Supports up to 30W per port, providing power and data connectivity for PoE-enabled devices like wireless access points and IP phones.
- 4 x 10GbE SFP+ Uplink Ports: Provides high-speed uplinks for fast network expansion and improved performance.
- 370W PoE Power Budget: Powers multiple PoE devices simultaneously, simplifying network infrastructure by eliminating the need for additional power sources.
- Advanced Layer 2 and Layer 3 Features: Includes VLANs, static routing, OSPF, and QoS for enhanced traffic management and network control.
- Centralized and Local Management: Managed via Aruba Central, CLI, or web-based GUI, offering easy deployment and monitoring.
Technical Overview
- Recommended for: Enterprises, branch offices, and SMBs requiring high-performance, scalable networking solutions.
- Ports: 48 x 1GbE PoE+ ports, 4 x 10GbE SFP+ uplinks
- Switching Capacity: 176 Gbps
- Forwarding Rate: 130.9 Mpps
- PoE Power Budget: 370W for powering multiple PoE-enabled devices.
- Management: Managed via Aruba Central, CLI, or web-based GUI
- Energy Efficiency: Compliant with IEEE 802.3az standards for energy-efficient operation.
